Compactors, Rollers & Paving
Ditch Compactor
Compact material in a narrow ditch with a vibrating wheel attachment. Trench width, lift thickness, vibration exposure, and carrier stability require review.
View productCompactors, Rollers & Paving
Vibratory Roller
- Steel roller width
- 1670 mm
- Vibration force
- 3540 kg
- Height
- 610 mm
- Weight
- 800 kg
Vibratory Roller size comparison
| Specification | 66 in | 72 in |
|---|---|---|
| Steel roller widthmm | 1670 | 1855 |
| Roller diametermm | 600 | 600 |
| Vibration forcekg | 3540 | 3880 |
| Vibration frequencyvpm | 2600 | 2600 |
| Weightkg | 800 | 900 |
| Lengthmm | 1848 | 2000 |
| Widthmm | 900 | 900 |
| Heightmm | 610 | 610 |
Product information
Description
Compact compatible soil and aggregate surfaces with documented 66 and 72 inch configurations.
Tools for leveling, conditioning, compacting, raking, and preparing surfaces.
Fitment-first search
Select your machine
Serial numbers are used only to review fitment. Do not enter ownership or payment information.
Related products
Compactors, Rollers & Paving
Lawn Paver
A specialist paving wheel documented for preparing or pressing lawn surfaces. The supplier name, material, pass method, and surface conditions require confirmation.
View product
Compactors, Rollers & Paving
Plate Compactor
Compact soil or aggregate with a hydraulically driven plate. Material, lift thickness, trench clearance, vibration exposure, and carrier limits require review.
View productProduct questions
Vibratory Roller FAQs
What work is Vibratory Roller intended for?
Compact compatible soil and aggregate surfaces with documented 66 and 72 inch configurations.
Will Vibratory Roller fit every skid steer?
No. Confirm the loader make, model, serial number, rated capacity, and mounting interface before treating Vibratory Roller as a candidate. A compatible coupler alone does not confirm suitability for the machine or job.
Which hydraulic or electrical details are needed for Vibratory Roller?
If the attachment is powered, provide auxiliary flow and pressure, coupler type, case-drain requirement, electrical connector, and control method. These requirements must be checked against the carrier.
Which job details affect Vibratory Roller selection?
Describe the material, required working width or capacity, target result, site conditions, obstacles, slope, and expected duty cycle. These details help determine whether the attachment configuration is appropriate.
What should I submit for a Vibratory Roller quote?
Send the machine plate, coupler and hose photos, hydraulic and electrical information, attachment dimensions, intended job, and any readable labels or markings. Availability and final compatibility are confirmed during quote review.
