Soil Conditioner
- Working width
- 1670 mm
- Swing angle
- ±18 °
- Working pressure
- 16 MPa
- Weight
- 420 kg
Soil Conditioner size comparison
| Specification | 66 in | 72 in | 84 in |
|---|---|---|---|
| Working widthmm | 1670 | 1830 | 2130 |
| Swing angle° | ±18 | ±18 | ±18 |
| Working pressureMPa | 16 | 16 | 16 |
| Weightkg | 420 | 550 | 620 |
| Lengthmm | 1500 | 1500 | 1500 |
| Widthmm | 1700 | 1850 | 2150 |
| Heightmm | 600 | 600 | 600 |
Product information
Description
Prepare and condition soil with three documented working widths and ±18-degree articulation. Soil type, drum tooling, pressure, and loader capacity require review.
Tools for leveling, conditioning, compacting, raking, and preparing surfaces.
Fitment-first search
Select your machine
Serial numbers are used only to review fitment. Do not enter ownership or payment information.
Related products
Blades, Graders & Soil Preparation
Land Leveler
Level loose material and prepare jobsite surfaces with a documented 72 inch configuration.
View product
Blades, Graders & Soil Preparation
Soil Tiller
Break and blend soil across the documented 1,300 mm tilling width for landscaping and ground preparation.
View productProduct questions
Soil Conditioner FAQs
What work is Soil Conditioner intended for?
Prepare and condition soil with three documented working widths and ±18-degree articulation. Soil type, drum tooling, pressure, and loader capacity require review.
Will Soil Conditioner fit every skid steer?
No. Confirm the loader make, model, serial number, rated capacity, and mounting interface before treating Soil Conditioner as a candidate. A compatible coupler alone does not confirm suitability for the machine or job.
Which hydraulic or electrical details are needed for Soil Conditioner?
If the attachment is powered, provide auxiliary flow and pressure, coupler type, case-drain requirement, electrical connector, and control method. These requirements must be checked against the carrier.
Which job details affect Soil Conditioner selection?
Describe the material, required working width or capacity, target result, site conditions, obstacles, slope, and expected duty cycle. These details help determine whether the attachment configuration is appropriate.
What should I submit for a Soil Conditioner quote?
Send the machine plate, coupler and hose photos, hydraulic and electrical information, attachment dimensions, intended job, and any readable labels or markings. Availability and final compatibility are confirmed during quote review.
