Blades, Graders & Soil Preparation
Dozer Blade
Push and shape material during site preparation.
View productBlades, Graders & Soil Preparation
Soil Tiller
- Working width
- 1300 mm
- Hydraulic flow
- 50–125 L/min
- Height
- 800 mm
- Weight
- 450 kg
Soil Tiller specifications
| Specification | 1,300 mm working width |
|---|---|
| Hydraulic flowL/min | 50–125 |
| Working pressureMPa | 16–21 |
| Working widthmm | 1300 |
| Implement widthmm | 1600 |
| Implement lengthmm | 700 |
| Lengthmm | 890 |
| Overall widthmm | 1600 |
| Heightmm | 800 |
| Weightkg | 450 |
Product information
Description
Break and blend soil across the documented 1,300 mm tilling width for landscaping and ground preparation.
Tools for leveling, conditioning, compacting, raking, and preparing surfaces.
Fitment-first search
Select your machine
Serial numbers are used only to review fitment. Do not enter ownership or payment information.
Related products
Product questions
Soil Tiller FAQs
What work is Soil Tiller intended for?
Break and blend soil across the documented 1,300 mm tilling width for landscaping and ground preparation.
Will Soil Tiller fit every skid steer?
No. Confirm the loader make, model, serial number, rated capacity, and mounting interface before treating Soil Tiller as a candidate. A compatible coupler alone does not confirm suitability for the machine or job.
Which hydraulic or electrical details are needed for Soil Tiller?
If the attachment is powered, provide auxiliary flow and pressure, coupler type, case-drain requirement, electrical connector, and control method. These requirements must be checked against the carrier.
Which job details affect Soil Tiller selection?
Describe the material, required working width or capacity, target result, site conditions, obstacles, slope, and expected duty cycle. These details help determine whether the attachment configuration is appropriate.
What should I submit for a Soil Tiller quote?
Send the machine plate, coupler and hose photos, hydraulic and electrical information, attachment dimensions, intended job, and any readable labels or markings. Availability and final compatibility are confirmed during quote review.
